| Model | SA-750D | SA-750DB | SA-750E | SA-750EB |
|---|---|---|---|---|
|
Color |
Bronze |
Black |
Black |
Black |
|
Effective length (from the tonearm pivot to stylus point) |
305mm |
305mm |
229mm |
228mm |
|
Distance of the tonearm pivot to spindle |
290mm |
290mm |
214mm |
210mm |
|
Overhang (spindle to stylus point) |
15mm |
15mm |
15mm |
18mm |
|
Offset angle |
19° |
19° |
22° |
21.45° |
|
Tracking error angle |
+1.42° – 0.97° |
+1.42° – 0.97° |
+1.9° – 1.1° |
+2.0° – 1.5 ° |
|
Holizontal sensitivity (first action inner wire free) |
30mg |
30mg |
30mg |
30mg |
|
Vertical sensitivity (first action inner wire free) |
20mg |
20mg |
20mg |
20mg |
|
Suitable cartridge weight range for standard counterweight |
4 – 12gr |
4 – 12gr |
4 – 12gr |
4 – 12gr |
|
Suitable cartridge weight range for heavier counterweight |
12 – 24gr |
12 – 24gr |
12 – 24gr |
12 – 24gr |
|
Range of height adjustment (distance between the arm base bottom and center of the arm pipe) |
38 – 60mm |
38 – 60mm |
38 – 60mm |
38 – 60mm |
