Specifications

Volume setting for unity gain • 84

Input overload • 5 Volts rms

Bandwidth Into >600 Ohms • 0 Hz-200 kHz

Signal to Noise Ratio re 1 volt out • >100 dB A weighted, 20-20KHz

Distortion at 1 Volts rms Out • <0.01%

Input configuration and impedance • Single-ended/balanced 20K ohm

Output Options • 2-XLR Balanced; 2-RCA; 1-buffered RCA Tape Out Output Impedance • 50 ohms

Maximum Output Level • 10 volts rms Balanced

Gain Single-ended • 16 dB

Gain Balanced • 16 dB

Input Sample Rates: 32 to 96kHz
Bit Depth: 16 to 24 Bit
Signal to Noise Ratio: >112 dB, A-weighted
Dynamic Range: 112 dB
Total Harmonic Distortion: <0.003%
Frequency Response: 0 to 48kHz –3 dB
Output Impedance: 50 ohms
Output Level: 2 Vrms
Input Options: 1 Toslink optical; 1 SPDIF coaxial RCA-type

Power Requirements • 100-120 VAC 50-60 Hz or 230-240 VAC 50-60 Hz 25VA
