AW 300 M

AW 300 M 是 Electrocompaniet 最新推出的單聲道功率擴大機。這款擴大機採用了煥然一新但又極具辨識度的 Electrocompaniet 設計，與 Electrocompaniet 現有和以往的產品系列完美契合。
TECHNICAL SPECIFICATIONS

Input impedance: 330 kΩ
Frequency response (input filter active) : 0.5 – 220 kHz
Frequency response (input filter disabled):0.5 – 1.1 MHz
Voltage gain (balanced input) : 29 dB (x28)
Input-referred noise (20-20 kHz): < 2 µV
SNR (ref. 1 W/8 Ω load, 20-20 kHz): 95 dB
SNR (ref. full power output, 20-20 kHz): 120 dB
Slew-rate (input filter disabled): 140 V/µs
IMD: < 0.001 %
Damping factor (8 Ω load): > 1000
DC output voltage: < 5 mV
THD+N: 0.0006 %
Power consumption standby: < 0.5W
Protection: DC, overload, temperature

WEIGHT & DIMENSIONS:
Weight: 30 kg – 66 lbs
Width: 470 mm – 8.34 inches
Depth: 490 mm – 19.21 inches (including GND terminal)
Height: 210 mm – 11.4 inches (including feet)
*Features and specifications are subject to change without further notice.
