Description

Designed for use with the Quad II or 22 pre-amplifiers

The function of a main amplifier is that of amplifying the output from the control unit or other source with the highest possible standard of accuracy.

This is achieved in the Quad II to a degree unexcelled by any equipment known to be offered to the public.

The amplifier is further unique in that this performance is obtained with stability which is complete.

Specifications

Power output: 15 watts into 8Ω (mono)

Frequency response: 20Hz to 20kHz

Total harmonic distortion: 0.25%

Input sensitivity: 1.4V

Signal to noise ratio: 80dB

Speaker load impedance: 7Ω to 15Ω

Valve complement: 2 x EF86, 2 x KT66, 1 x GZ32

Dimensions: 13 x 4.75 x 6.5 inches

Weight: 18.25lbs

Finish: stoved steel grey
