Main performance indicators:

Pre amplifier part:

Input impedance: 47KΩ.

Voltage gain: 9.5dB±0.5dB.

Frequency response: 5Hz～20KHz ±0.5dB.

Signal-to-noise ratio: ≥100dB (A-weighted).

Maximum output voltage: ≥12Vrms (THD≤0.1%).

Nonlinear distortion: ≤0.03% (10Hz～20KHz, 1.5V).

Power amplifier section:.

Input impedance: 100KΩ

Voltage gain: 29.5dB ± 0.3dB (1KHz)

Output Power:

2×150W (8Ω)

2×300W (4Ω)

Frequency response: 5Hz～20KHz ±1dB

Nonlinear distortion: ≤0.2% (20～20KHz, 150W, 8Ω)

Damping:≥200

Signal-to-noise ratio: ≥116dB (A-weighted)

Whole machine:

Working power: AC220V (±10%) 50/60Hz 800W (MAX)

Dimensions: 434mm (W) × 180mm (H) × 420mm (D)

Weight: 25Kg
