Specifications

Volume setting for unity gain • 84

Input overload • 5 Volts rms

Bandwidth Into >600 Ohms • 0 Hz-200 kHz

Signal to Noise Ratio re 1 volt out • >100 dB A weighted, 20-20KHz

Distortion at 1 Volts rms Out • <0.01%

Input configuration and impedance • Single-ended/balanced 20K ohm

Output Options • 2-XLR Balanced; 2-RCA; 1-buffered RCA Tape Out Output Impedance • 50 ohms

Maximum Output Level • 10 volts rms Balanced

Gain Single-ended • 16 dB

Gain Balanced • 16 dB

Power Requirements • 100-120 VAC 50-60 Hz or 230-240 VAC 50-60 Hz 25VA

Size • 17.5”W x 15”D x 4”H (mm x mm x mm) Weight • 14lbs. (6.5kg)
